RV-400: 8 m (26.2 ft), RV-4xx (P/S): 2 m (6.5 ft), An 8 m (26.2 ft) extension cable is also supplied when ordering split pair transducer sets T70450 and T70451.

Dimensions

Length: 347.51 mm (13.68 in) including High speed nose cone. Height: 180 mm (7.09 in) including cable bend radius. Width: 114.00 mm (4.49 in) - including High speed nose cone

Weight

3.12 kg (6.88 lb)

Waterproof rating

IPx6 (surfaces exterior to hull only), IPx7, IPx8

Storage temperature range

-20°C (23°F) to + 70°C (158°F)

Operating temperature range

-2°C (28.4°F) to + 55°C (131°F)

Standards

EN 60945:2002, IEC 28846:1993, EMC Directive 2014/30/EU, Australia and New Zealand: C-Tick, Compliance Level 2

Range

CHIRP sonar = 0.6 M (2 ft) to 274 m (900 ft), DownVision = 0.6 M (2 ft) to 183 m (600 ft), SideVision = 0.6 M (2 ft) to 91 m (300 ft), RealVision 3D = 0.6 M (2 ft) to 91 m (300 ft)

Channels

1 x CHIRP sonar, 1 x DownVision, 1 x SideVision, 1 x RealVision 3D
