EV-1 Sensor Core
OEM: E70096
View on Raymarine ↗
1 / 2
Main
Compatible Boats
1 fitmentLeopard 482013-2016
Original part
Related Products
No related products linked yet.
Customer Reviews
No reviews yet for this product.
Where to Buy
Search at Retailers
West MarineUSUS delivery; some oversized, hazmat, freight, and international restrictionsShip: Checkout rates vary by destination, service, and item class
DefenderUSUS and international shipping options depend on item and destinationShip: Checkout/carrier quote; oversize, hazmat, and truck freight vary
Fisheries SupplyUSUS-focused delivery with quote-based exceptions for restricted freightShip: Checkout/carrier quote; oversize and hazardous items can add charges
PartsVuUS + intlUS, territories, and international checkoutShip: $11.99 flat / free $99+; oversize quoted
Searching for: "Raymarine E70096"
Product Details (12)
Relative humidity
Max. 93%
Waterproof rating
IPx6
Storage temperature
-30 °C to +70 °C (-22 °F to 158 °F)
Operating temperature
-25 °C to +55 °C (-13 °F to 131 °F)
Standards
Europe: 2004/108/EC, Australia and New Zealand: C-Tick, Compliance Level 2
Dimensions
Diameter: 140 mm (5.5 in), Depth (including mounting enclosure): 35 mm (1.4 in), Depth (including wall bracket): 95 mm (3.8 in)
Sensors
3-axis digital accelerometer, 3-axis digital compass, 3-axis gyro digital angular rate sensor
Weight
0.29 kg (0.64 lbs)
Nominal supply voltage
12 V dc
Operating voltage range
10.8 V dc to 15.6 V dc
Power consumption
30 mA
LEN (NMEA 2000 Load Equivalency Number)
1
